Standard potentiometer or hall throttle (0.8–4.2V), joystick mode, direct PWM input (0–95%), or RC PWM receiver input 1.5ms ±1ms. Fits any installation out of the box.
Captures kinetic energy back into the battery during braking. Essential for EV conversions and forklifts where efficiency matters. 2-quadrant operation in one direction.
18 kHz switching frequency for whisper-quiet operation. Precise 0–98% duty cycle control with adjustable acceleration ramp from 0 to 40 seconds.
Adjustable normal current limit from 0–50A, with 70A peak capacity. Protects both motor and controller from overload, extending system lifespan significantly.
Completely controllable via TX/RX serial connector with extended parameter access. Integrate directly with PLCs, microcontrollers, Raspberry Pi, Arduino, and more.
Just 65 × 76 × 28 mm and 100 g without heatsink. M6 high-current connections on all power terminals. Designed for tight installations in EVs, boats, and industrial machinery.
| Max Voltage | 50V DC |
| Normal Output Current | 0–50A (adjustable) |
| Peak Current | 70A |
| Supply Voltage Range | 10–50V DC (universal) |
| Switching Frequency | 18 kHz |
| Duty Cycle | 0–98% |
| Processor | 32-bit ARM Cortex |
| Control Modes | 4 modes (potentiometer, hall, PWM, RC) |
| Speed Control Input | 0–5V universal analog/PWM |
| Acceleration Ramp | 0–40 seconds (adjustable) |
| Braking | Regenerative (energy recovery) |
| Operation | 2-quadrant (drive + regen) |
| Power Connections | M6 bolts (high-current rated) |
| Serial Communication | TX/RX connector |
| Dimensions | 65 × 76 × 28 mm |
| Weight | 100 g (board only) |
Perfect for electric bike, scooter, kart, or motorcycle builds. Handles regenerative braking for extended range.
Reliable current limiting and regen braking make it ideal for material-handling vehicles in warehouse environments.
Compact and lightweight with wide voltage range. Salt-air resilient board design for marine thruster applications.
Serial interface enables seamless PLC integration. PWM and analog inputs work with any industrial control system.
RC PWM receiver input ready. Arduino and Raspberry Pi compatible via serial. Great for autonomous robot drives.
Plug-and-play setup with standard potentiometer support. No coding required for basic speed control applications.
